| Output efficiency | 3000-3500UPH |
| Over all | 2270*2000*1880mm(Length, width, height, Host + Tray +tape+ monitor) |
| Support IC packaging | QFN,SOP,SSOP,TSSOP,SON,QFP... |
| Pick and place device | Vacuum nozzle*4 |
| Programming Station | 48-32 |
| Monitor | 24''LCD |
| Pick and place accuracy | ±0.03mm |
| Way to control | Motion Control Card |
| GPS | CCD (optional) |
| Burning method | Down-press burning seat |
| Tray in and out | Automatic tray feeding device, supports up to 20 trays |
| Tape Input | Standard 12-16mm optional 8 32mm feeder |
| Tape output | Adjustable hot-pressing automatic film sealing device |
| Input voltage | AC220/50ZHz. |
| Power | 1.3kw |
| Gas source | 0.4-0.6MPA |
| Total weight | 900KG |
