| Project | Index |
| Detection matrix | Fe matrix |
| Detection time | Depends on sample type, generally 10-30s |
| Detector | 16 high-precision CCDS |
| Optical system | Pa-Runge structure, Rowland light source |
| Wavelength range | 120~800nm |
| Focal length | 400mm |
| Gas system | Dual gas path four-nozzle gas path system, built-in flow meter |
| Light source system | Full-frequency digital double-pulse excitation light source, variable frequency (100-1000HZ) excitation technology. |
| Working humidity | 20%~80% |
| Readout system | High-speed 16-bit ADC analog-to-digital conversion, FPGA digital signalcontroller,industrial USB data acquisition. |
| Inspiring Platform | The whole is made of wear-resistant and corrosion-resistant Cr stainless steel and has an argon-excited intelligent air pressure protection device. |
| Aperture of the excitationstage | 99.999% |
| Argon inlet pressure | 0.5MPa |
| Argon flow rate | Excitation flow rate: about 3.5L/min |
| Excitation maximum power Average | 600W |
| standby power | 100W |
| Size | 810(L)x660(D)x380(H) |
| Weight | Approx. 80 kg |
